Correct use method of wire rope buckle
Many friends do not know the correct use of wire rope buckles. Below, Luoyang Baikte Technology Development Co., Ltd. will explain it to you.
Wire rope chuck is also called wire rope buckle. The wire rope chuck is mainly used for the temporary connection of the wire rope, the fixing of the rear hand rope when the wire rope is wound around the pulley set, and the fixing of the wind rope rope head on the derrick, including phosphating coated wire rope, galvanized wire rope, stainless steel wire rope and smooth wire rope. It is a wide range of wire rope clamps used in lifting operations. There are 3 types of wire rope clamps that are commonly used: riding type, fist grip type and pressing plate type. Among them, the riding card is a standard wire rope clip with very strong connection force and is widely used. Secondly, the press plate type is only used in secondary places because there is no base, which is easy to damage the wire rope and the connection force is poor.
1. When selecting rope clamp, the side net distance of U-shaped ring should be about 1~3mm larger than the diameter of steel wire rope. If the net distance is too large, the connection in the buckle will not tighten the steel wire rope, causing sliding and accidents.
2. The bolts of the buckle must be tightened, generally based on the flattened diameter of the wire rope.
3, U-shaped part should be in contact with the wire rope head, can not be reversed with the main rope; rope clamp installation to a smooth, equidistant arrangement.
4. In order to check whether the rope clamp joint is safe and reliable or to find out whether the wire rope joint is sliding in time, another rope clamp is generally added about 500mm behind the latter rope clamp, and the wire rope head is released into a "safe bend"; If the wire rope joint slips, the phenomenon that the "safe bend" is straightened can be visually displayed, and timely treatment measures should be taken at this time.
